FLXA21是YOKOGAWA（橫河）品牌的一款模塊化兩線制液體分析儀，它具備多種功能和特點，適用于多種工業環境的測量需求。以下是對FLXA21的詳細解析：
一、產品概述
品牌與型號：YOKOGAWA（橫河）/FLXA21
類型：模塊化兩線制液體分析儀
功能：能夠靈活配置，用于測量pH/ORP（氧化還原電位）、接觸式電導率（SC）、感應式電導率（ISC）或溶解氧（DO）等多種參數。
二、主要功能與特點
模塊化設計：
FLXA21采用模塊化設計，可以連接不同的傳感器模塊，實現多種測量目的。
它支持同時連接兩臺相同型號的傳感器，降低安裝成本，節省空間，并配置高度可靠的雙傳感器測量系統。
高精度測量：
具備高測量精度和分辨率，如電導率測量范圍可達0～1999mS/cm，精度可達0.001μS/cm。
溶解氧測量范圍可達0～50mg/l(ppm)，精確度達0.001。
先進功能：
觸摸屏設計，增強操作性，具有簡單的HMI菜單結構，支持多種語言（包括中文）顯示。
傳感器自診斷功能，可連續測量電阻率、不對稱電位、斜率等，并診斷傳感器狀態。
維護時間預估功能，幫助用戶合理安排維護計劃。
通信與防爆等級：
支持一路4～20mA DC輸出和雙向HART?數字通信。
防爆等級包括ATEX、IECEx、FM等（部分認證正在申請中）。
外殼與材質：
提供多種外殼選擇，包括塑料、不銹鋼或帶抗腐蝕涂層的不銹鋼，以滿足不同工業環境的需求。
防護等級高，如NEMA4X、IP66，確保設備在惡劣環境下的穩定運行。
擴展性與兼容性：
支持SD卡和藍牙通信，降低安裝和布線成本。
可與多種傳感器和通信設備兼容，實現靈活的系統構建。
三、應用場景
FLXA21廣泛應用于化工、食品、制藥、電鍍涂裝、造紙等行業，特別適用于酸、堿和鹽溶液濃度監視以及電導率測量等應用。其高精度、高可靠性和多功能性使其成為工業在線測量的理想選擇。
The FLXA21 is a modular two-wire liquid analyzer from YOKOGAWA that offers a wide range of functions and features to meet the measurement needs of a wide range of industrial environments. The following is a detailed analysis of FLXA21:
I. Product overview
Make and Model: YOKOGAWA /FLXA21
Type: Modular two-wire liquid analyzer
Function: Flexible configuration to measure pH/ORP (REDOX potential), contact conductivity (SC), inductive conductivity (ISC) or dissolved oxygen (DO).
2. Main functions and characteristics
Modular design:
The modular design of the FLXA21 allows different sensor modules to be connected for a variety of measurement purposes.
It supports the simultaneous connection of two sensors of the same model, reducing installation costs, saving space, and configuring a highly reliable dual-sensor measurement system.
High precision measurement:
With high measurement accuracy and resolution, such as conductivity measurement range of 0 ~ 1999mS/cm, accuracy up to 0.001μS/cm.
The dissolved oxygen measurement range is 0 ~ 50mg/l(ppm) with an accuracy of 0.001.
Advanced Features:
Touch screen design, enhanced operability, with a simple HMI menu structure, support for multiple languages (including Chinese) display.
The sensor self-diagnosis function can continuously measure resistivity, asymmetric potential, slope, etc., and diagnose the sensor status.
The maintenance time estimation function helps users reasonably arrange maintenance plans.
Communication and explosion-proof rating:
Supports one 4 to 20mA DC output and two-way HART? digital communication.
Explosion-proof grades include ATEX, IECEx, FM, etc. (some certifications are being applied for).
Shell and material:
A variety of housing options are available, including plastic, stainless steel or stainless steel with corrosion resistant coatings to meet the needs of different industrial environments.
High protection levels, such as NEMA4X and IP66, ensure stable operation of equipment in harsh environments.
Scalability and compatibility:
Support SD card and Bluetooth communication, reduce installation and wiring costs.
Compatible with a wide range of sensors and communication devices, enabling flexible system construction.
3. Application scenarios
FLXA21 is widely used in chemical, food, pharmaceutical, electroplating coating, paper and other industries, especially for acid, alkali and salt solution concentration monitoring and electrical conductivity measurement applications. Its high precision, high reliability and versatility make it ideal for industrial online measurement.
