5069-L320ER |5SHY5045L0020|控制器|
概述
適合需要低運動軸數和 I/O 點數的小型應用程序到大型應用程序
支持高速 I/O、運動控制、設備級環網和線性拓?fù)浣Y(jié)構
提供一個 1 千兆 (Gb) 嵌入式 EtherNet/IP 端口，以便使用 CIP 安全連接、I/O和安全設備
包括可配置的雙端口，支持雙 IP 地址
提供增強的診斷和故障處理功能，并且顯示控制器狀態和故障
提供為盡可能發揮系統性能優化過的控制器功能
提供增強的安全功能，包括基于控制器的變更檢測、記錄、加密固件以及基于角色的例程和用戶自定義指令訪問控制
支持多達 31 個本地 Compact 5000? I/O 模塊
提供基于 EtherNet/IP 的集成運動控制，最多支持 32 個軸
提供范圍廣泛的存儲選項，從 0.6 MB 到 10 MB
Compact GuardLogix 5380 安全控制器
使用 1oo1 架構實現 SIL 2/PLd 或使用 1oo2 架構實現 SIL 3/PLe
提供 0.6 MB 10 MB 的標準內存選件
提供 0.3 MB 5 MB 的安全內存選件
提供 1 千兆 (Gb) 嵌入式 Ethernet 端口
支持適合多達 180 個 EtherNet/IP 節點的通信選件
提供能夠抵御惡劣環境的敷形涂覆選件
提供單控制器/軟件/網絡，實現標準和安全控制
提供混合和匹配安全及標準 I/O 的功能
提供與驅動器和運動集成的安全功能
能夠從 PanelView? 800 圖形終端連接縮放的 HMI 選項
控制器安裝在DIN導軌上。它們可以監視和控制本地和遠程I/O模塊，以及連接到EtherNet/P網絡的其他設備?？刂破髦С?/span>
此功能:
使用緊湊型5000 1/0標準和安全模塊作為本地1/0和遠程I/O模塊。申使用緊湊型5000 I/O模塊和其他I/O模塊作為遠程I/O模塊。
支持EtherNet/IP網絡上的集成運動(并非所有控制器)。
使用雙IP模式或線性/DLR模式。
使用兩個以太網端口，讓控制器連接到EtherNet/IP設備級和企業級網絡。使用非易失性存儲器的1784-SDHC8,1784-SDHC32,9509-CM SD CD4安全數字(SD)卡。用于臨時連接的USB編程端口。
緊湊型GuardLogix 5380控制器具有保形涂層。順應涂層提供一層保護，防止污染物和潮濕，幫助保護組件，并在惡劣的腐蝕性環境中延長產品使用壽命。具有表面涂覆層的產品在目錄編號的未尾有一個'K'后綴。
summarize
Suitable for small applications that require low number of axes of motion and I/O points to large applications
Supports high-speed I/O, motion control, device-level ring networks, and linear topologies
Provides a 1 gigabit (Gb) embedded EtherNet/IP port for secure connections, I/O, and secure devices using CIP
It includes configurable dual ports and supports dual IP addresses
Provides enhanced diagnostic and troubleshooting capabilities, and displays controller status and faults
Provides controller functions optimized for maximum system performance
Provides enhanced security features, including controller-based change detection, logging, encrypted firmware, and role-based routine and user-defined instruction access control
Supports up to 31 local Compact 5000? I/O modules
Provides integrated motion control based on EtherNet/IP and supports up to 32 axes
A wide range of storage options are available, from 0.6MB to 10MB
Compact GuardLogix 5380 Security controller
SIL 2/PLd is implemented using 1oo1 architecture or SIL 3/PLe is implemented using 1oo2 architecture
Standard memory options of 0.6MB and 10MB are available
Provides 0.3 MB 5 MB safe memory option
1 Gigabit (Gb) embedded Ethernet port available
Supports communication options for up to 180 EtherNet/IP nodes
Offers shape coating options that can withstand harsh environments
Single controller/software/network for standard and security control
Provides the ability to mix and match security and standard I/O
Provides security features integrated with drives and motion
The HMI option for scaling can be connected from the PanelView? 800 graphics terminal
The controller is mounted on a DIN rail. They can monitor and control local and remote I/O modules, as well as other devices connected to EtherNet/P networks. Controller support
This feature:
The compact 5000 1/0 standard and security module is used as a local 1/0 and remote I/O module. Shin uses the compact 5000 I/O module and other I/O modules as remote I/O modules.
Support for integrated motion on EtherNet/IP networks (not all controllers).
Use dual IP mode or linear /DLR mode.
Use two EtherNet ports to connect the controller to EtherNet/IP device-level and enterprise-level networks. 1784-SDHC8,1784-SDHC32,9509-CM SD CD4 secure digital (SD) cards using non-volatile memory. USB programming port for temporary connections.
The compact GuardLogix 5380 controller features a conformal coating. Compliant coatings provide a layer of protection against contaminants and moisture, help protect components and extend product life in harsh, corrosive environments. Products with a surface coating have a 'K' suffix at the end of the catalog number.
