>>>>>型號:REF615C-D 饋線保護和測控裝置 高靈敏度和選擇性的接地故障保護
【功能描述】
高靈敏度和選擇性的接地故障保護
REF615 IEC 饋線保護和測控裝置，作為專用饋線保護和測控裝置，專門用于保護、控制、測量和監視公共和工業配電系統。REF615 既可以適應中性點不接地電網又可以適應中性點電阻或阻抗接地電網。此外，利用裝置先進的站級間通信功能，REF615 也可以用于環形網狀配電網絡或輻射網絡保護。被保護的電網包含多次饋電和分布式發電。
REF615 IEC 饋線保護和測控裝置具備 12 種標準配置，適應于常用的饋線保護和測控應用。REF615 的特點是支持變電站 IEC61850 通信標準，并行冗余協議（PRP）和高可用性無縫冗余度協議（HSR），其中 IEC61850 通信標準包含 IEC 61850-9-2 LE。該繼電器還支持 DNP3，IEC 60870-5-103 和 Modbus? 規約。通過 SPA-ZC 302 規約適配器支持 Profitbus DPV1 規約。
REF615 IEC 饋線保護和測控裝置是 ABB Relion? 產品家族中的 615 產品系列的成員。
主要優勢
集成在一臺繼電保護裝置中的保護、控制、監測和管理為公共和工業配電系統提供了緊湊和通用的方案
具有廣泛的保護和控制功能，可以用傳感器或傳統的 CT、PT
具有預配置好的標準配置，這樣可以更快更容易地進行組合，滿足用戶不同的應用需求
快速安裝和測試的可插拔式設計
帶單線圖顯示的大液晶屏，可通過本地或易于連接和瀏覽的 HMI 來訪問
周到的產品全壽命周期服務
主要優勢
方向過流、無方向過流、接地保護，電壓、頻率和電能質量保護及測量功能
具有高靈敏度和選擇性的多頻導納接地保護組合
具有可選擇的先進、快速的短路、接地故障定位功能
支持 IEC61850 第一版和第二版，包括冗余 HSR 和 PRP, GOOSE 和 IEC61850-9-2
支持 IEEE 1588 v2 高精密時間協議
支持 Modbus、DNP3，IEC 60870-5-103 通信協議
>>>>>型號:REF615C-D 饋線保護和測控裝置 高靈敏度和選擇性的接地故障保護
【英文介紹】
High sensitivity and selective ground fault protection
REF615 IEC Feeder protection and measurement and control devices are specialized feeder protection and measurement and control devices designed to protect, control, measure and monitor public and industrial distribution systems. The REF615 can be adapted to both neutral ungrounded and neutral resistance or impedance grounded networks. In addition, the REF615 can also be used for ring mesh distribution networks or radiation network protection, using the device's advanced interstation communication capabilities. The protected grid includes multiple feeds and distributed generation.
The REF615 IEC feeder protection and measurement unit is available in 12 standard configurations for common feeder protection and measurement applications. The REF615 features support for the substation IEC61850 communication standard, Parallel Redundancy Protocol (PRP), and High Availability Seamless Redundancy Protocol (HSR), where the IEC61850 communication standard includes IEC 61850-9-2 LE. The relay also supports DNP3, IEC 60870-5-103 and Modbus? protocols. The Profitbus DPV1 protocol is supported through the SPA-ZC 302 protocol adapter.
The REF615 IEC feeder protection and measurement and control unit is a member of the 615 product family in ABB's Relion? product family.
Major advantage
Protection, control, monitoring and management integrated in a single relay protection unit provides a compact and versatile solution for public and industrial distribution systems
With a wide range of protection and control functions, it can be used with sensors or traditional CT, PT
With pre-configured standard configurations, it can be combined faster and easier to meet the different application needs of users
Pluggable design for quick installation and testing
Large LCD screen with single line chart display, accessible locally or through an HMI that is easy to connect and browse
Thoughtful product life cycle service
Major advantage
Directional overcurrent, no directional overcurrent, ground protection, voltage, frequency and power quality protection and measurement functions
Multi-frequency admittance ground protection combination with high sensitivity and selectivity
Optional advanced and fast short-circuit and ground fault location
IEC61850 1st and 2nd editions are supported, including redundant HSR and PRP, GOOSE and IEC61850-9-2
Support IEEE 1588 v2 high precision time protocol
Supports Modbus, DNP3, and IEC 60870-5-103 communication protocols
