3BSE076355R1(PM867K01) | DO810 3BSE008510R1 | 控制器
型號： 3BSE076355R1(PM867K01)
冗余 不
高完整性 是的
時鐘頻率 133兆赫
性能，1000 個布爾運算 0.09 毫秒
性能 0.09 毫秒
記憶 64兆字節
RAM可用于應用 46.559兆字節
用于存儲的閃存 不
詳細數據
環境與認證
尺寸
寬度 119毫米(4.7英寸)
高度 186毫米(7.3英寸)
深度 135毫米(5.3英寸)
重量(包括底座)1200克(2.6 磅)
CPU 板包含微處理器和 RAM 存儲器、實時時鐘、LED 指示燈、INIT 按鈕和 CompactFlash 接囗。
PM867 控制器的底板有兩個用于連接控制網絡的 R45 以太網端口(CN1、CN2)和兩個R45 串行端口(COM3、COM4)。其中一個串行端口(COM3)是帶有調制解調器控制信號的 RS.
232C端口，而另一個端口(COM4)是隔離的，用于連接的置工具。控制器支持 CPU冗余以實現更高的可用性(CPU、CEX 總線、通信接口和 S800 /O0)。
通過添加 SM812 模塊和 SL認證軟件，可實現高完整性功能。AC 800M High-integny還提供 IEC61508 和TOV 認證的控制環境，可在不犧牲安全完整性的情況下將安全和關鍵業務過程控制
結合在一個控制器單元中。
僅兼容 800xA 6.0.2 及更高版本。有關詳細信息，請參閱產品更新。
Model: 3BSE076355R1(PM867K01)
Redundant not
High integrity Yes
Clock frequency 133 MHZ
Performance, 0.09 milliseconds for 1000 Boolean operations
Performance 0.09 ms
64 megabytes of memory
RAM can be used for application 46.559 megabytes
The flash memory used for storage is not
Detailed data
Environment and certification
dimension
Width 119 mm (4.7 in)
Height 186 mm (7.3 in)
Depth 135 mm (5.3 in)
Weight (including base)1200 g (2.6 lb)
The CPU board contains the microprocessor and RAM memory, real-time clock, LED indicator, INIT button, and CompactFlash interface.
The baseboard of the PM867 controller has two R45 Ethernet ports (CN1 and CN2) and two R45 serial ports (COM3 and COM4) for connecting to the control network. One of the serial ports (COM3) is the RS with the modem control signal.
The 232C port, while the other port (COM4) is isolated and used for connecting the tool. The controller supports CPU redundancy for higher availability (CPU, CEX bus, communication interface, and S800 /O0).
With the addition of the SM812 module and SL certification software, high integrity functionality can be achieved. The AC 800M High-integny also offers IEC61508 and TOV certified control environments that keep security and critical business processes under control without sacrificing security integrity
Combined in a single controller unit.
Only compatible with 800xA 6.0.2 and later. For more information, see Product Updates.
