NTAI06 | 端子板 | SNAT607 MCI | NTAI06
型號：NTAI06
類別：端子板
成色：全新/非全新
質保：一年
快遞：順豐/德邦
端子板是一種用于電氣連接的電子元器件，其主要作用在于方便各種電器元器件之間的連線。以下是關于端子板的詳細介紹：
一、定義與構成
端子板，也被稱為接線板或插針板，通常由一個可固定于電子設備外殼上的基板和一排用于連接電線或其他電氣組件的端子條構成。這些端子條上設有用于夾緊電線的結構，以確保電線與端子之間的緊密電氣連接。
二、功能特點
模塊化結構：NTAI06端子板采用模塊化設計，包括信號輸入輸出、電源分配等功能，使得控制柜內的接線附件更加標準化和系列化。這種設計不僅美觀，而且提高了工作效率。
功能全面：端子板具有信號隔離和驅動、回路供電、卡件供電、信號指示、報警指示、回路保護、電源保護、信號轉接等多項功能，可支持多品牌安全柵和隔離器，全面提升配線質量。
簡化設計與布線：NTAI06通過板上跳線的型式，解決了外部設備與系統卡件接線的差異化和復雜化問題，使得同一個卡件可以接駁不同類型的儀表和信號，減少了線路節點，簡化了施工圖紙設計和盤內布線過程。
省略端子排：NTAI06外部接線端配備的拔插式接線端子塊可方便端子維修，更換端子板可不拆除接線。內部接線端采用專用接口，使用特制電纜與PLC或DCS快速插接，提高了工作效率。
Model: NTAI06
Category: Terminal board
Finish: New/not new
Warranty: One year
Express: SF Express/Debon
The terminal board is an electronic component used for electrical connection, and its main function is to facilitate the connection between various electrical components. The following is a detailed introduction to the terminal board:
I. Definition and composition
A terminal board, also known as a patch board or pin board, usually consists of a substrate that can be fixed to the housing of an electronic device and a row of terminal strips for connecting wires or other electrical components. These terminal strips are provided with a structure for clamping the wire to ensure a tight electrical connection between the wire and the terminal.
Second, functional characteristics
Modular structure: NTAI06 terminal board adopts modular design, including signal input and output, power distribution and other functions, making the wiring accessories in the control cabinet more standardized and serialized. This design is not only beautiful, but also improves the work efficiency.
Comprehensive function: the terminal board has a number of functions such as signal isolation and drive, loop power supply, card power supply, signal indication, alarm indication, loop protection, power protection, signal switching, etc., which can support multi-brand safety grid and isolator, and comprehensively improve the wiring quality.
Simplified design and wiring: NTAI06 through the type of jumper on the board, to solve the difference and complex problems of external equipment and system card wiring, so that the same card can be connected to different types of instruments and signals, reduce the line node, simplify the construction drawing design and the wiring process in the disk.
Omit terminal block: The external terminal of NTAI06 is equipped with a plug and insert terminal block to facilitate terminal maintenance. Replacing the terminal board does not remove the cable. The internal terminal uses a special interface, and uses a special cable to quickly plug into PLC or DCS, which improves the work efficiency.
