>>>>型號:PM36218B-10P-1-8PH-J 磁性元件
【功能描述】
PM36218B-10P-1-8PH-J是一款高性能的磁性元件，主要用于抑制高頻噪聲和電磁干擾（EMI）。它由Pioneer Magnetics公司生產，是一種表面貼裝鐵氧體磁珠。
以下是關于PM36218B-10P-1-8PH-J的詳細規格和特點：
尺寸與規格：
尺寸為10mm x 1mm x 0.5mm。
在100MHz時具有820歐姆的電阻值。
額定電流為50mA。
溫度范圍：
工作溫度范圍非常寬，從-55°C到+150°C，這顯示了其極端環境條件下的適應能力。
應用領域：
由于其高磁導率和高頻應用能力，PM36218B-10P-1-8PH-J適用于電子設備中的EMI抑制和電源濾波等應用場景。
此外，這款磁珠還具有以下特性：
低電阻：有助于減少能量損失和提高效率。
高磁導率：增強了其電磁干擾抑制能力。
高溫穩定性：保證了在各種溫度條件下都能穩定工作。
綜上所述，PM36218B-10P-1-8PH-J是一款功能強大、性能穩定的磁性元件，適用于各種要求嚴格的工業和商業環境。
>>>>>型號:PM36218B-10P-1-8PH-J 磁性元件
【英文介紹】
The PM36218B-10P-1-8PH-J is a high-performance magnetic component designed to suppress high-frequency noise and electromagnetic interference (EMI). Manufactured
by Pioneer Magnetics, it is a surface-mount ferrite magnetic bead. The following are the detailed specifications and features of the PM36218B-10P-1-8PH-J:
Dimensions and Specifications:
The dimensions are 10mm x 1mm x 0.5mm.
It has a resistance value of 820 ohms at 100MHz.
The rated current is 50mA.
Temperature range:
The operating temperature range is very wide, from -55°C to +150°C, which shows its adaptability to extreme environmental conditions.
Application field:
Due to its high permeability and high frequency application capability, the PM36218B-10P-1-8PH-J is suitable for application scenarios such as EMI suppression and power
filtering in electronic devices.
In addition, this magnetic bead also has the following characteristics:
Low resistance: helps to reduce energy loss and improve efficiency.
High permeability: enhanced electromagnetic interference suppression capability.
High temperature stability: It ensures stable operation under various temperature conditions.
In summary, the PM36218B-10P-1-8PH-J is a powerful and stable magnetic component suitable for a variety of demanding industrial and commercial environments.
