>>>>>型號:503-26606-21 運動控制器
【功能描述】
503-26606-21 運動控制器
QDIO 16/16數字模塊用于擴展MSC或MSC II的本地輸入和輸出(I/0)運動控制器。
模塊安裝在DIN導軌上并直接連接到MSC I或MSC II運動控制器，或遠程數字/0模塊(RDIO)通過內部擴展總線(e總線)。
數字1/0的配置按軟件通過穆格的中央控制配置軸控軟件開發環境。前面的led燈顯示設備的狀態信息l/0。
led的排列對應于連接I/0。數字?jǐn)U展模塊的I/0被驅動直接從MSC|，MSC II運動控制器或RDIO搭乘電子巴士。
一個MSC|或MSC II運動控制器可以擴展最多7個模塊(例如QDI0或QAIO)。進一步數字l/0可以通過RDIO模塊驅動，這是連接到MSC I或MSC II運動控制器CANopen。
>>>>>型號:503-26606-21 運動控制器
【英文介紹】
503-26606-21 Motion controller
The QDIO 16/16 digital module is used to extend the local input and output (I/0) motion controllers
of the MSC or MSC II. Modules are mounted on DIN rails and connected directly to MSC I or MSC II
motion controllers, or remote Digital /0 modules (RDIO) via an internal expansion bus (E-bus).
The number 1/0 is configured by software to configure the shaft control software development
environment through Moog's central control. The led light on the front displays the status information l/0 of the device.
The arrangement of leds corresponds to the connection I/0. The I/0 of the digital expansion module is
driven directly from the MSC|, MSC II motion controller or RDIO on the e-bus. An MSC| or MSC II motion controller
can be extended up to 7 modules (e.g. QDI0 or QAIO). Further digital l/0 can be driven via the RDIO module, which is connected to the MSC I or MSC II motion controller CANopen.
