>>>>>型號:8200-1300 集成式圖形化前面板 設計用于控制單或雙
【功能描述】
伍德沃德的 8200-1300 為汽輪機提供數字控制。它是 505 渦輪機控制系列中可用的幾種數字調速器之一。本機使用符合標準的 LVDC （18-32 VDC） 電源。
本機可用于非危險場所。它也適用于 I 類 2 分區 A/B/C/D 組位置。該裝置通常安裝有額定溫度至少為 75 攝氏度的絞合銅現場布線。
8200-1300 可以控制單分體式或雙分體式執行器汽輪機。它可以配置為工廠DCS（分布式控制系統）的一部分，也可以作為獨立單元使用。它設計有五個 PID 控制器，包括一個速度/負載 PID 控制器、一個級聯 PID 控制器以及 AUX1 和 AUX2 PID 控制器。該裝置提供操作員控制面板，包括圖形控制面板顯示屏和鍵盤。該面板包括一個緊急停止按鈕、開始、停止、esc 和主頁按鈕、一個數字鍵盤和切換向上/向下按鈕，以及一個帶有向上/向下和向左/向右按鈕的回車鍵。該面板的左側還有四個 LED，包括 CPU 運行狀況、IO 鎖定、摘要警報和摘要跳閘。
在內部，8200-1300 包括一個看門狗定時器和一個 CPU 故障電路，用于監控微處理器及其存儲器的運行情況。
>>>>>型號:8200-1300 集成式圖形化前面板 設計用于控制單或雙
【英文介紹】
Woodward's 8200-1300 provides digital control for steam turbines. It is one of several digital governors available in the 505 turbine control series. The unit uses a standard LVDC (18-32 VDC) power supply.
This machine can be used in non-hazardous places. It is also available for Class I 2 partition A/B/C/D group locations. The unit is usually fitted with stranded copper field wiring with a temperature rating of at least 75 degrees Celsius.
The 8200-1300 can control a single or double split actuator turbine. It can be configured as part of a factory DCS (Distributed control System) or used as a stand-alone unit. It is designed with five PID controllers, including a speed/load PID controller, a cascade PID controller, and AUX1 and AUX2 PID controllers. The unit provides an operator control panel comprising a graphic control panel display and keyboard. The panel includes an emergency stop button, start, stop, esc, and home buttons, a numeric keypad and toggle up/down buttons, and a return key with up/down and left/right buttons. There are also four leds on the left side of the panel, including CPU health, IO lock, summary alert, and summary trip.
Internally, the 8200-1300 includes a watchdog timer and a CPU fault circuit to monitor the operation of the microprocessor and its memory.
>>>>>型號:8200-1300 集成式圖形化前面板 設計用于控制單或雙
