>>>>型號:ELOPII 控制系統 具有數據緩沖的功能
【功能描述】
ELOPII是是一種控制系統。
ELOPII可以作為DCS（分布式控制系統）控制器使用，也可以作為ABB DCS的備件。此外，ELOPII組件還包括控制器、卡件和控制模塊等，這些組件共同構成了PLC（可編程邏輯控制器）系統的一部分。
ELOPII的輸出模塊具有數據緩沖的功能，可以暫存由主機高速傳來的數據，并以I/O設備所具有的速率將數據傳送給設備，從而保證數據傳輸?shù)男屎驼_性。此外，它還具備差錯控制的功能，能夠?qū)τ?/p>
I/O設備傳送來的數據進行差錯檢測，確保數據輸入的正確性。
ELOPII組態步驟：
打開ELOPII軟件后，首先創建新的工程。
選擇指定的控制器型號，例如H51qe-HES。
設置控制器地址，如網卡RESxxx01:01表示一對CPU的BSN地址。
根據需要設置模擬量顯示與通道狀態故障對應地址。
進行刪除點操作，可以通過雙擊位號，去掉勾選，刪除各字段。
同樣設置冗余卡通道，并應用后確認是否允許relode設置（不設置只能DOWNLODE）
>>>>型號:ELOPII 控制系統 具有數據緩沖的功能
【英文介紹】
ELOPII is a control system.
ELOPII can be used as a DCS (Distributed Control System) controller or as a spare part for ABB DCS. In addition, ELOPII components also include controllers, cards and control modules, which together
form part of the PLC (Programmable logic Controller) system.
The output module of ELOPII has the function of data buffering, which can temporarily store the data from the host at high speed, and transmit the data to the device at the rate of the I/O device, so
as to ensure the efficiency and correctness of data transmission. In addition, it also has the function of error control, which can detect the error of the data transmitted by the I/O device to ensure the correctness of the data input.
ELOPII configuration steps:
After opening the ELOPII software, first create a new project.
Select the specified controller model, for example, H51qe-HES.
Set the controller address. For example, NIC resxxx01.01 indicates the BSN address of a pair of cpus.
Set the address corresponding to the channel status fault for analog display as required.
To delete a point, double-click the bit number and uncheck it to delete each field.
Also set redundant cartoon channels, and confirm whether relode Settings are allowed after application (no setting can only DOWNLODE)
