>>>>>型號:DS200CPCAG1ABB 功率繼電器 內部有活動部件
【功能描述】
GE接觸器先導板DS200CPCAG1ABB具有一個12針連接器和兩個2針連接器。它還具有四個接線端子，最多可連接12根信號線。GE接觸器先導板DS200CPCAG1ABB還裝有24VDC 15A插座功率繼電器。
繼電器內部有活動部件，因此在驅動器中安裝電路板時需要仔細考慮。如果繼電器撞到驅動柜內的金屬結構或其他組件，則很容易損壞。而且繼電器很高，從板子表面突出，很容易被擊中。將主板滑入驅動器機柜時，請確保您能清楚地看到主板和機柜內部。慢慢插入電路板并將其與機架上的螺釘對齊。一只手將螺釘插入孔中，另一只手轉動螺絲刀以固定螺釘。但是，不要將電路板固定得太緊，以致螺絲使電路板破裂，從而損壞電路板。如果墊圈在有缺陷的電路板上提供或使用墊圈，請使用墊圈。
>>>>>型號:DS200CPCAG1ABB 功率繼電器 內部有活動部件
【英文介紹】
The GE contactor pilot plate DS200CPCAG1ABB has one 12-pin connector and two 2-pin connectors. It also has four terminals and can connect up to 12 signal wires. The GE contactor pilot board DS200CPCAG1ABB is also equipped with a 24VDC 15A socket power relay.
There are moving parts inside the relay, so careful consideration is required when installing the circuit board in the driver. If the relay hits the metal structure or other components in the drive cabinet, it is easily damaged. And the relay is high, protruding from the surface of the board and easy to hit. When sliding the motherboard into the drive cabinet, make sure you have a clear view of the motherboard and the inside of the cabinet. Slowly insert the board and align it with the screws on the rack. Insert the screw into the hole with one hand and turn the screwdriver with the other hand to secure the screw. However, do not secure the board so tightly that the screws break the board and damage it. If the washer is supplied or used on a defective circuit board, use a washer.
>>>>>型號:DS200CPCAG1ABB 功率繼電器 內部有活動部件
