SLS1508 RRS3202 |T8110B型|冗余邏輯求解器|
硬件:
冗余邏輯求解器(SLS 1508)和終止塊
SISNet中繼器(參見單獨的產品數據表)
載波擴展電纜
冗余sls1508邏輯求解器。
本地對等總線擴展電纜
右1寬載波終端
邏輯求解器(SLS 1508)包含邏輯求解功能
并提供一個接口到16個I/O通道,可以
配置為離散輸入,
離散輸出,模擬輸入
(HART)和HART兩態輸出通道。邏輯解決者
終端塊安裝在8寬的載體上。
邏輯求解器之間通過
運營商通過雙通道,本地對等總線(SISnet)和遠程
同行的戒指。本地邏輯求解器由相同的delta托管
控制器和遠程邏輯求解器由不同的
均控制器。邏輯求解器由24v直流電源供電
電源與驅動電動機的電源是分開的
DeltaV控制器和I/O。邏輯解算器以奇數安裝
插槽(1,3,5,7)上的8寬載體。冗余邏輯求解器
使用四個插槽
Hardware:
Redundant logic solver (SLS 1508) and termination block
SISNet Repeater (see separate product data sheet)
Carrier extension cable
Redundant sls1508 logic solver.
Local peer bus extension cable
Right 1 wide carrier terminal
The logic solver (SLS 1508) contains the logic solver function
And provide an interface to 16 I/O channels, yes
Configured for discrete input, discrete output, analog input
(HART) and HART two state output channels. Logical solver
The terminal block is mounted on an 8-wide carrier.
Logic solvers pass between them
Operators operate through dual channels, local peer-to-peer bus (SISnet) and remote
A companion ring. The local logic solver is hosted by the same delta
Controllers and remote logic solvers are different
Equalizing controller. The logic solver is powered by a 24v DC supply
The power supply is separate from the power supply that drives the motor
DeltaV controller and I/O. Logical solvers are installed in odd numbers
Slots (1,3,5,7) on the 8-wide carrier. Redundant logic solver
Use four slots
