VE4001S2T2B5 | 終端模塊 | 實現數據的傳輸
品牌 ： DeltaV
產品編號： VE4001S2T2B5
產品類型 ： DeltaV? M系列傳統I/O
VE4001S2T2B5 ： 40引腳大規模終端模塊
通道數 ： 32
隔離：每個通道都與系統進行光學隔離 并在工廠測試至 1500V DC
開啟檢測電平：>2 mA
關機檢測電平：<0.25 mA
輸入阻抗：5K歐姆(近似值)
每張卡的本地總線電流(12V DC 標稱值)：典型值為 50 mA，最大值為 75 mA
每卡現場電路功率：150 mA(24V DC)
重量 ： 2 Kg
VE4001S2T2B5終端模塊，也稱為端子連接器、連接端子或螺絲端子，是一種集成電路芯片，廣泛應用于需要安全連接電氣系統的各種應用。它非常適用于需要安全、井然有序且半永久電線連接的設計，這些連接可以在現場輕松更換進行檢查或維修。
VE4001S2T2B5 終端模塊的作用主要體現在以下幾個方面：
數據傳輸和通信：通過其內部的收發器和射頻芯片，終端模塊可以與其他設備進行無線信號的接收和發送，實現數據的傳輸和通信。
設備管理：VE4001S2T2B5 終端模塊還可以實現對接入設備的運行狀態、位置、開機關機控制、調試診斷以及系統升級等管理功能。
協議轉換：在物聯網應用中，終端模塊可以將不同終端設備的通信協議轉化為物聯網標準協議進行數據傳輸，實現設備間的互聯互通。
此外，VE4001S2T2B5 終端模塊的類型多種多樣，包括PCB安裝(通常稱為Eurostyle或線到板終端模塊)等，可以根據具體的應用場景和需求進行選擇。
Brand: DeltaV
Product Number: VE4001S2T2B5
Product Type: DeltaV? M Series Traditional I/O
VE4001S2T2B5:40-pin large-scale terminal module
Number of channels: 32
Isolation: Each channel is optically isolated from the system and factory-tested to 1500V DC
Enable detection level: >2 mA
Shutdown detection level: < 0.25mA
Input impedance: 5K ohm (approximate)
Local bus current per card (12V DC nominal value) : Typical value 50 mA, maximum 75 mA
Field circuit power per card: 150 mA (24V DC)
Weight: 2 Kg
The VE4001S2T2B5 terminal module, also known as a terminal connector, connection terminal or screw terminal, is an integrated circuit chip used in a wide variety of applications where electrical systems need to be securely connected. It is ideal for designs that require secure, well-ordered and semi-permanent wire connections that can be easily replaced on site for inspection or repair.
The functions of the VE4001S2T2B5 terminal module are mainly reflected in the following aspects:
Data transmission and communication: through its internal transceiver and RF chip, the terminal module can receive and send wireless signals with other devices to achieve data transmission and communication.
Device management: The VE4001S2T2B5 terminal module can also realize the management functions of the running status, position, power on and off control, debugging diagnosis and system upgrade of the access device.
Protocol conversion: In the application of the Internet of Things, the terminal module can convert the communication protocol of different terminal devices into the standard protocol of the Internet of Things for data transmission, and realize the interconnection between devices.
In addition, the VE4001S2T2B5 terminal modules are available in a wide variety of types, including PCB mounting (commonly referred to as Eurostyle or wireline to board terminal modules), which can be selected according to specific application scenarios and needs.
