【功能描述】
監測器通道成對編程，每次最多能完成上述的兩個功能。通道1和2能完成一個功能，而通道3和4能實現另外一個(或同一個)功能。但是，只有通道3和4能實現殼脹監測。
傳感器靈敏度軸向位置:3.937 mV/mm(100 mV/mil)或7.874 mV/mm(200 mV/mil)
差脹:0.394 V/mm(10 mV/mil)或0.787 V/mm(20 mV/mil)
斜面式差脹:0.394 V/mm(10 mV/mil)或0.787 V/mm(20 mV/mil)或3.937 V/mm(100 mV/mil)或7.874 V/mm(200 mV/mil)
補償輸入式差脹:0.394 V/mm(10 mV/mil)或0.787 V/mm(20 mV/mil)或3.937 V/mm(100 mV/mil)
DC LVDT殼脹:0.05 V/mm(1.25 V/in)或0.08 V/mm(1.90 V/in)或0.10 V/mm(2.50 V/in)或0.18 V/mm(4.50 V/in)或0.20 V/mm(5.00 V/in)或0.22 V/mm(5.70 V/in)
AC LVDT殼脹:28.74 mV/V/mm(0.73 mV/V/mil)或15.35 mV/V/mm(0.39 mV/V/mil)或9.45 mV/V/mm(0.24 mV/V/mil)
差脹/軸向位置監測器3500/45-AXX-BXX選項描述
A:I/O模塊
0 1位置I/O模塊，帶有內部端子(電渦流傳感器,RPT,DC LVDT)
0 2位置I/O模塊，帶有外部端子(電渦流傳感器,RPT,DC LVDT)
0 3分散式TMR位置I/O模塊，帶有外部端子(電渦流傳感器或DC LVDT)
0 4母線連接TMR位置I/O模塊，帶外部端子(電渦流傳感器)
0 5 AC LVDT位置I/O模塊，帶內部端子
0 6 AC LVDT位置I/O模塊，帶外部端子
0 7旋轉電位計位置I/O模塊，帶內部端子
0 8旋轉電位計位置I/O模塊，帶外部端子
B:批準機構選項
0 0無
0 1 CSA/NRTL/C
140072-04 3500/45差脹/軸向位置監測器
135137-01用于電渦流傳感器、RPT或DC LVDT的帶內部端子的位置I/O模塊
135145-01用于電渦流傳感器、RPT或DC LVDT的帶外部端子的位置I/O模塊
135145-01用于電渦流傳感器、RPT或DC LVDT的帶外部端子的TMR I/O模塊
126632-01只用于電渦流傳感器的母線式帶外部端子的TMR I/O模塊
139554-01 AC LVDT位置I/O模塊，帶內部端子
139567-01 AC LVDT位置I/O模塊，帶外部端子
139978-01旋轉電位計位置I/O模塊，帶內部端子
139991-01旋轉電位計位置I/O模塊，帶外部端子
bently nevada 3500/45-01-00(176449-04,135137-01)本特利差脹模塊接受本特利電渦流傳感器傳來的信號。
>>>>>型號:149986-01 16通道繼電器控制模塊 監測器通道
【英文介紹】
Features:
3500 Interface between the monitoring system and System 1 mechanical management software
Combine 3500/20 RIM functionality with a communications processor
Works with M-series displays
The Bentley Nevada 3500/22M Series Transient Data Interface (TDI) is the mechanical management software for the interface between the 3500 monitoring system and the Bentley Nevada System 1. TDI combines the capabilities of 3500/20 rack interface modules with the data collection capabilities of communication processors such as TDXnet.
The TDI runs in a RIM slot in the 3500 rack with M-series monitors (3500/40m, 3500/42m, etc.) to continuously collect steady-state and transient waveform data and pass this data to the host software over an Ethernet link. Static data capture is standard with TDI, but using an optional channel-enabled disk also allows capturing dynamic or transient data. In addition to integrating communications processor capabilities in 3500 racks, the TDI improves on previous communications processors in several ways.
The TDI provides certain functions common to the entire rack. However, the TDI is not part of the critical monitoring path and has no impact on the normal operation of the entire monitoring system. Each rack requires one TDI or RIM. The TDI occupies only one slot in the rack and is always located in the Slo t 1 (next to the power supply).
For triple modular redundancy (TMR) applications, the 3500 system requires the TMR version of TDI. In addition to all standard TDI functions, TMR TDI also performs "monitor channel comparison." 3500 TMR configuration performs monitoring voting using the Settings specified in Monitoring options. In this way, TMR TDI continuously compares the output of three (3) redundant monitors. If TMR detects that the information in one of the monitors is no longer equivalent to the remaining two monitors (within the configured percentage), it flags the monitor as an error and puts the event in the system event list.
